MAX MEGATRON 1400 HP PRO Commercial Brushless 24V DC SWGO w/BBU

In stock

SKU

max:mega1400hppro

Manufacture MAP price: $5504
Login for lower price
If you dont have an account, create here

High Profile, High Traffic, Heavy Duty, Commercial, Brushless, DC, Swing Gate Operator. Moves up to 1400 lbs / 15ft or 1200 lbs / 20ft

Wishlist Compare

Mechanical Specifications

Max Megatron 1400 HP PRO dimensions (18.3 W x 24.5 D x 21.3 H) 18.5 arm height

Heavy duty gear box 900:1 Size 70 for Megatron 1400 HP PRO

Megatron 1400 HP PRO capacity 1400lbs/15ft or 1200lb/20ft – gate speed 11 1⁄2 to 18 seconds

Large output shaft 3 1/4” diameter solid steel with cast iron clamping system for all Megatron

Direct gear drive (no chains, belts, or pulleys)

Mechanical and electrical manual gate release functions

Corrosion protection gold zinc coating

Continuous cycle at extreme temperature range. No overheating possibility

Intelligent ramp-up and ramp-down gate speed control for smooth operation

Shipping weight of Max Megatron 1400 HP PRO (235 lbs)

Brushless DC motor equivalent to 1/2 HP AC motor
Programmable gate speed controls, 16 selectable speeds
Automatic gate position reset system
Gate sync feature provides automatic gate movement synchronization
Modular system design for ease of service
Switchable 115/230V AC selection
Adaptive DSP control for advanced brushless DC motion control
Real time performance analyzer and event log (OBD PORT and Black Box)
Low voltage wiring capabilities for remote power up 1000 feet (no battery needed)
Solar ready battery module with built-in advanced solar regulator
Intelligent power management system with energy saver mode
Built-in current limited 12vdc and 24vdc outputs
Gold contact input connections and automobile grade connectors
Selectable open timer 0 to 60 seconds with timer off option
-4F to 165F (-20C to +74C) operational temperature range including battery performance without needing a heater
Robust lightning protection up to 20KVolts and 10KAmps on all inputs and outputs (44 Channels) including loop detector input connections
Tunable 16 position safety obstruction sensor, auto adaptable to gate weight and size
Dual motor overcurrent safety shut off for additional protection
This operator has battery backup providing 400 cycles in case of power failure
Three modes of selectable battery backup functions
State machine design electronics with ultra-fast microprocessor
On board three button station

High traffic intuitive loop management system for better security
Advanced security features with built-in audible and remote alarms
Magnetic lock control relay outputs with selectable delay times
Tamper alert relay outputs triggered “on” if gate is forced open
Audible alarm if gate is tampered with or ERD is triggered for higher security
Gate partial open recorder
Lockable cover with key lock release to prevent intruders and vandalism
Gate disable feature, disables all inputs with exception of the fire department input for high security
Built–in transaction buffer for high security
Gate status outputs for gate monitoring
Direct motor control of jog OPEN/CLOSE for manually moving a gate in case of emergency
Advanced anti-tailgate features to provide higher security
No need for magnetic lock with the robust output shaft and clamp design of the Max Megatron 1400 HP PRO

Adaptive obstruction sensor for much better gate safety system. 16 selectable sensitivity settings
UL 325/991 compliant Class I, II, III, and IV. CSA approved
Pinch arm protection design
Dynamic magnetic brake system stops the gate immediately to prevent damage to obstructions
Vehicle hit protection technology protects the gate operator from collision damage caused by automobile impact, avoiding costly repairs
Built-in advanced entrapment protection and alarm output
Built-in gate in motion alarm for industrial applications

Insurance Price Type	Fixed
Motor Size	1/2 Hp
Duty Type	Commercial, Commercial/Industrial, Industrial
Max Gate Weight	1,400
Max Gate Width	20
